High Temperature Stability
Good Exchangeability
Good Durability
Low Insertion Loss
High Back Reflection Loss
Standard: Telcordia GR-326-CORE
Connector | LC to LC | Polish Type | UPC to UPC |
Fiber Mode | OM4 50/125µm | Wavelength | 850/1310nm |
Insertion Loss | ≤0.3dB | Return Loss | ≥50dB |
Fiber Grade | G.651A | Min.Bend Radius | 7.5mm |
Attenuation at 850nm | ≤3dB/km | Attenuation at 1310nm | ≤1dB/km |
Fiber Cout | Duplex | Cable Diameter | 2.0mm |
Cable Jacket | LSZH | Polarity | A(Tx)-B(Tx) |
Operating Temperature | -20℃ to +70℃ | Storage Temperature | -40℃ to +85℃ |
